1 |
|
|
199012320121 |
1 |
环 |
Ring |
|
S29 (6x4) |
|
2 |
|
|
Q150B1230TF2 |
12 |
六角头螺栓 |
Hex.screw |
|
K29 (6x4) |
|
3 |
|
|
199012320103 |
1 |
轴承座 |
Bearing seat |
用于 i=5.73、6.72、7.49、8.40、 |
K38 (6x4) |
|
3 |
|
|
|
|
|
|
9.49 |
043 (6x4) |
|
3 |
|
|
199012320131 |
1 |
轴承座 |
Bearing seat |
用于 i=4.8、4.42 |
064 (6x4) |
|
4 |
|
|
199012320173 |
按需 |
调整垫片 |
Adjusting washer |
|
N56 (6x4) |
|
4 |
|
|
199012320174 |
按需 |
调整垫片 |
Adjusting washer |
|
N60 (6x4) |
|
4 |
|
|
199012320175 |
按需 |
调整垫片 |
Adjusting washer |
|
B30 (8x4) |
|
4 |
|
|
199012320176 |
按需 |
调整垫片 |
Adjusting washer |
|
B36 (8x4) |
|
5 |
|
|
199012320133 |
1 |
密封圈 |
Seal ring |
|
SX2190 (6x |
|
6 |
|
|
199012320097 |
1 |
主减速器壳 |
Main drive housing |
|
6) |
|
7 |
|
|
190003888457 |
16 |
自锁螺母 |
Self-locking nut |
|
S35 (4x2) |
|
8 |
|
|
Q12316120 |
4 |
双头螺柱 |
Stud |
|
K38 (4x2) |
|
9 |
|
|
199012320002 |
2 |
差速器轴承盖 |
Differential bearing cover |
|
046 (4x2) |
|
10 |
|
|
Q58116 |
4 |
六角开槽螺母 |
Hex.nut |
|
N56 (4x2) |
|
11 |
|
|
Q5004030 |
4 |
开口销 |
Cotter pin |
|
F50 (4x2) |
|
12 |
|
|
Q123B1230 |
4 |
双头螺柱 |
Stud |
|
N60 (4x2) |
|
13 |
|
|
58633015 |
1 |
磁性螺塞总成 |
Magnetic plug assembly |
|
SX2151 (4x |
|
14 |
|
|
Q72336 |
2 |
密封垫圈 |
Seal washer |
|
4) |
|
15 |
|
|
Q5210820 |
4 |
圆柱销 |
Pin |
|
SX2180M (4x |
|
16 |
|
|
190003989290 |
1 |
碗形堵塞 |
Cup plug |
|
4) |
|
17 |
|
|
Q2540820 |
4 |
十字槽沉头螺钉 |
Slit bolt |
|
044 (6x2) |
|
18 |
|
|
Q5211014 |
1 |
圆柱销 |
Cyl.pin |
|
|
|
19 |
|
|
199014330147 |
1 |
弓形固定卡总成（上） |
Bow hold-open catch assembly |
|
|
|
20 |
|
|
199014330146 |
1 |
弓形固定卡总成（下） |
Bow hold-open catch assembly |
|
|
|
21 |
|
|
680M3200015 |
1 |
〇形密封圈 |
O- ring |
|
|
|
22 |
|
|
199014330125 |
1 |
操纵杆总成 |
Operation handle assembly |
|
|
|
23 |
|
|
179100710003 |
1 |
压力开关 |
Pressure switch |
|
|
|
24 |
|
|
81500010163 |
1 |
螺塞 |
Plug screw |
|
|
|
25 |
|
|
190003964418 |
1 |
叉形活节 |
Y-tape hinge |
|
|
|
26 |
|
|
178000350055 |
1 |
ES平头锁 |
Flat head lock |
|
|
|
27 |
|
|
Q350B08T15 |
1 |
六角薄螺母 |
Hex.nut |
|
|
|
28 |
|
|
179100360018 |
1 |
工作缸 |
Spring storage cylinder |
|
|
|
29 |
|
|
Q33208 |
1 |
II型全金属锁紧螺母 |
Locking nut |
|
|
|
30 |
|
|
Q40108 |
1 |
平垫圈 |
Flat washer |
|
|
|
31 |
|
|
61000060084 |
1 |
间隔衬套 |
Space bush |
|
|
|
32 |
|
|
Q1200850F3 |
1 |
双头螺柱 |
Stud |
|
|
|
33 |
|
|
199000330006 |
1 |
通气口总成 |
Air vent assembly |
|
|
|
34 |
|
|
199012330065 |
1 |
后桥壳总成 |
Rear axle lousing assembly |
|
|
|
34 |
|
|
DZ9112330065 |
1 |
加强后桥壳总成 |
Strength rear axle housing assembly |
|
|
|
34 |
|
|
DZ9112332066 |
1 |
后桥壳总成（淬火加强型） |
Rear axle housing assembly |
|
|
|
34 |
|
|
DZ9112330165 |
1 |
后桥壳总成（850车架） |
Rear axle housing assembly |
|
|
|
35 |
|
|
138000932157 |
1 |
圆螺母（右） |
Circle nut |
|
|
